Chain Block 6 Meters - Overload Protection 3.0T
Quantity:
Pickup available at Action Outdoors Shop
Usually ready in 24 hours
Chain Block 6 Meters - Overload Protection 3.0T
Action Outdoors Shop
Pickup available, usually ready in 24 hours
1/348 Rosebank Road
Avondale
AUK
Auckland 1026
New Zealand
Chain Block 6M NXTGEN - Overload Protection 3.0 Tonne - Factory Pre-set Overload Protection System.
Chain Block 6M NXTGEN - Overload Protection 3.0T
The NXTGEN Chain Blocks feature advanced safety features, suitable for the most demanding industrial applications.
- 6 Meters
- 3.0 Tonne
"Overload Protection" will not allow this Chain Block to Lift above factory settings.
5-YEAR Limited Warranty
Key Features:
- Reduced Effort - High-Performance Gear System
- Secures Load - Active Instant Hold Load System
- Increased Safety - "OVERLOAD PROTECTION"
- Double Casing - Dust & Rainwater Resistant
- Zinc Plated G100 Load Chain
- International Standards AS1418.2
- Compact design, petite body, low headroom
- High-precision CNC Gears
- Impact-resistant gear cover
- Double pawl brake system
- The dust cover on the brake system
- Zinc-plated fixings, side plates and guides
- High-precision gears with four caged bearings
- Engineering optimized hand chain grooves and surface allows smooth operation pulling on various angles
- High-precision CNC load chain guides
- Factory Pre-set Overload Protection system
- Fused weather-protected ratchet-brake disc
- Zinc-plated G100 load chain
- Heavy-duty cast hook safety latches
- Dacromet coated parts
- Stainless steel Identification Plate
What Does Overload Protection Mean:
Generally, any brand hoist with "Overload Protection" has a built-in safety feature to ensure the user does not overload the hoist causing it to fail and/or injure to the user..
The manufacturers set the overload engagement to around 30% to 50% ABOVE the Maximum Working Load Limit (WLL), so on a 9.0T WLL Lever Hoist the overload system would engage around 12.0T (Approx 3.0T above its WLL)
Hoist Weight Packed: Standard 3M Lift
0.50T 12kg, 1.0T 14kg, 2.0T 21kg, 3.0T 25kg, 5.0T 45kg, 10.0T 88kg, 15.0T 155kg, 20.0T 210kg, 30.0T 290kg
