Thermographic Handheld Camera - 160 x 120

Thermographic Handheld Camera - 160 x 120 - This standalone handheld device will detect temperature remotely.

Thermographic Handheld Camera - 160 x 120

PLEASE CONTACT US FOR AVAILABILITY

Thermographic Handheld Camera - 160 x 120

This standalone handheld device will detect temperature remotely.

It can be used in a host of commercial applications as well as temperature detection and display of personnel

At a 0.8-1.5, meter distance detects multiple person’s temperatures live. Come with 8GB SD card for a local snapshot.

Functions:

Thermography Device detects the real-time temperature and displays it on the screen. Storage Device is equipped with a replaceable memory card to store recorded captured snapshots, and important data. Palette Device supports 4 palettes. Laser Light Supplement: Long-distance laser light supplement to point the thermography target.

Features

• High-sensitivity sensor with 160 x 120 resolution
• High quality 320 x 240 resolution 2.4'' LCD display
• Up to 4 palettes
• Wide temperature measurement range: -20 - 550° C
• High-temperature measurement accuracy: Up to ±2° C, ±2%
• Long-distance laser light supplement for thermography targets
• Built-in rechargeable Li-ion battery

Up to 8 hours of continuous operation

Thermal Module

• Image SensorUncooled Focal Plane Arrays
• Max. Resolution160 × 120
• NETD< 40mk (@ 25 °C,F#=1.0)
• Field Of View37.2° × 50 °
• ApertureF 1.1
• Pixel Pitch17μm
• Focal Length3.1 mm
• IFOV (Mrad)5.48 mrad
• Response Waveband8μm to 14μm

Image Display

• Monitor320 × 240 resolution 2.4’ LCD display
• PalettesBlack hot, White hot, Rainbow, Ironbow

Thermography

• Rules3 thermometry points: Max. Temperature; Min. Temperature; Center Temperature
• Thermometry Range-20 °C to 550 °C (-4 °F to 1022 °F)
• Thermometry AccuracyMax (±2 °C, ±2%)

Battery

• Battery TypeRechargeable Lithium Battery
• Battery Operating Time8 hours continuous running

Functions

• Laser LightSupport (Point to the thermography target)
• StorageReplaceable memory card (default 8G, support up to 128G storage)
• PhotoThermal image
• VideoN/A
• Language: English

General

• Power3.7 V DC/0.4 A
• Power consumption less than 1.2 W
• WeightApprox. less than 350 g (0.77 lb)
• Hardware Interfacemicro USB
• Protection LevelIP54
• Drop Test Height2 m (6.56 feet)
• Dimension196 mm × 117 mm × 59 mm (7.7 ″ × 4.6 ″ × 2.3 ″)
