CTEK MXS 10 - Universal Battery Charger 12V 10A

CTEK MXS 10 - Universal Battery Charger 12V 10A - Product Code CTEKMXS10 - A Charger for Your Caravan, Car and Boat.

CTEK MXS 10 - Universal Battery Charger 12V 10A

Features

CTEK MXS 10 - Universal Battery Charger 12V 10A

The MXS 10 is an ideal battery charger for your caravan, car and boat.

Thanks to its SUPPLY mode, the battery charger provides power even without a battery. The SUPPLY mode is indispensable when changing the battery as you avoid losing complicated program settings. Using RECOND mode, you can correct the acid stratification that often occurs in deeply discharged batteries. The battery thereby has its power restored and has a longer service life

• Eight-step, fully automatic switch mode model.
• Charges lead-acid batteries (Wet, MF, GEL and AGM) from 20Ah to 200Ah.
• Maintenance charge to 300AH.
• Maintenance pulse charging increases battery life and gives a superb performance.
• Supply mode for float maintenance for 100 per cent state of charge.
• Charges even drained batteries.
• Pulse recovery of slightly sulphated batteries.
• Four options: 14.4V, 14.7V, 13.6V/Supply and 15.8V/Boost.
• Low back current drain, low ripple and input voltage independent (170-260V).
• High efficiency: 85 per cent
• Delivered with connection lead with clamps.
• The charger can be connected for months, ideal for seasonal vehicles.
• Compact design with mounting holes for permanent assembly.
• 2-year warranty.

Charging

The MXS 10 has a fully automatic, eight-step charge

Setting 14.4V or 14.7V

• Desulphation - Runs a complete charge cycle within a fraction of a second. The cycle repeats during the whole desulphation phase. Every cycle recovers some lead sulphate into useful material.

• Start - Starting phase for charging. Charging with the limited charging current. The starting phase is over when the voltage rises above 10.5V, at which time the charger switches to bulk charging.

• Bulk - Charging where 80 per cent of the energy is returned. The charger delivers maximum current until the battery voltage has reached the set level.

• Absorption - The final part of the charge is up to 100 per cent. The battery voltage is kept constant at the set level, during which time the current drops gradually.

• Pulse - Maintenance charging. The state of charge varies between 95% and 100%. A pulse is sent out to the battery if the voltage drops. This keeps the battery in trim when not in use. The charger can be connected for months at a time.

Setting Supply

The supply mode setting supplies a constant voltage at 13.6V and current up to 7A. It could be used for maintenance charges using the float approach. This approach keeps the battery at a 100 per cent state of charge, but the constant small overcharge also increases water loss.


In this mode, the MULTI XS 7000 can also be used as a power supply unit for operating equipment that requires 13.6V and a maximum of 7A. The spark-free feature is disconnected in this setting.


Setting Boost 15.8V/1.5A/4h

The Boost setting gives a constant current at 1.5A, maximised at 16V for four hours. It will automatically switch to a 14.4V pulse set after four hours.


This mode is used for batteries that have been severely discharged.


Using the MXS 10 gives your battery optimum service life and operational reliability.

SETTINGS - EXPLANATION

14.4V - Normal setting for wet batteries, MF and for most Gel batteries.


14.7V - This setting is recommended for charging batteries at temperatures lower than -5 degrees C. It is also suitable for many AGM batteries.


13.6V/SUPPLY - In this mode, the charger delivers a constant voltage of 13.6V. This is the best maintenance mode for applications where maximum capacity from the battery is important. The MULTI XS 7000 can also be used as a power supply without a battery attached in this mode. No counter voltage is necessary to start the charger in this mode. Note that the spark-free function is suppressed in this mode; the reverse polarity protection works, but there is no indication.


16V/RECOND - This mode is used to recover severely discharged batteries where you might expect stratified acid (high acid weight at the bottom, low on top). Note that the battery has to be fully charged first. Use this mode with care, as the high voltage may cause some water loss. 16V is normally no problem for electronics in 12V systems, although maximum effect and minimum risk for electronics is achieved by disconnecting the battery.

THIS ITEM IS SHIPPED DIRECTLY FROM OUR SUPPLIERS

NZ Code CTEKMXS10

6-2024
